| | Print Method: Direct Thermal, Thermal Transfer
Print Speed: 102 mm/s
Print Resolution: 203 DPI (8 dots/mm)
Print Length: Min: 4 mm / Max: 1727 mm
Print Width: 108 mm
Printer language: EZPL, GEPL, GZPL auto switch
Printer Fonts: Bitmap fonts 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B, Bitmap fonts 8 times expandable in horizontal and vertical directions, Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable, TTF Fonts: CG Triumvirate™ (Bold / Italic / Underline ). 0°,90°, 180°, 270° rotatable
Download Fonts: 8 times expandable in horizontal and vertical directions, Asian Fonts 90°, 180°, 270° rotatable, Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable, TTF Fonts 90°, 180°, 270° rotatable
Graphics: Resident graphic file types are BMP and PCX, other graphic formats are downloadable from the software
Ribbon: Types: Wax, wax / resin, resin Length: 300 m Width: 30 mm – 110 mm Ribbon Roll Diameter: 68 mm Core Diameter: 25.4 mm
Processor: 32-bit RISC CPU
Memory: Flash: 8MB Flash (4 MB for user storage) SDRAM: 16MB
Sensor Type: Adjustable reflective sensor 2 fixed transmissive sensors, central aligned
Software Included: Label Design Software Labelpro (for EZPL only) Driver
Environmental Conditions: Operation Temperature: 5°C to 40°C Storage Temperature: -20°C to 50°C
Humidity Conditions: Operation 30-85%, non-condensing. Storage 10-90%, non-condensing.
Connectivity / Standard Ports: USB Devices (B-Type) Serial (RS-232)
وزن: 2.72 kg
ابعاد: 28.5 × 22.6 × 17.1 cm |
|---|
